MT Series fully rugged Windows tablets
High-performance rugged tablets, on-the-go
Are you tired of dealing with repair costs and downtime caused by ever-failing, consumer-grade tablets? Consider going rugged! Our extra durable tablets can withstand a four-foot drop onto concrete. They are dust-proof and water-resistant to IP65 standard and have an operating temperature range of -20 to +50°C / -4 to +122°F.
With their slim form factor and easy-to-read screen, these rugged tablets are perfect for both indoor and outdoor operations. No matter the lighting or weather conditions, your team can be ready for audits, special orders, inventory, or other on-the-go logistics tasks.
The MT™ series of rugged tablets can be customized to your specific requirements, boost your workforce and increase productivity. Keep your downtime to a minimum, go rugged today!
Highlights
Extended functionality
Maximized uptime
Perfect for work outside of the vehicle
Specifications
Please select a product below to view its specifications
Key features
- Windows operating system
- 10.1” display with optical bonding for sunlight viewability
- High-speed Intel® Core i5 Kaby Lake processor on MT2010S
- IP65 waterproof and dustproof
- Hot-swappable battery design
- Fully rugged construction
- Withstands a four-foot drop onto concrete
- So light and thin you can use it anywhere
Key features
- Intel® Core™ i5-1235U Alder Lake processor
- 10.1” 1920 x 1200 IPS LED panel with direct optical bonding
- Sunlight readable with antiglare solution
- Hot-swappable battery design
- USB Type-C port support PD 3.0 and ALT mode
- Integrated GigaLAN port
- MIL-STD-461G and MIL-STD-810H compliant
- IP65 waterproof and dustproof
Base Unit
PROCESSOR
Intel Core i5-1235U (up to 4.4GHz)
MEMORY
8GB DDR5 SDRAM, 16GB DDR5 SDRAM (optional)
32GB DDR5 SDRAM (optional
DISPLAY
10.1″ (1920×1200) 800 NIT
Optical bonding for sunlight viewability
Projected capacitive multi touch
Anti-glare touch treatment
Storage
STORAGE
256GB M.2 NVMe SSD
Additional storage available with micro SDXC card slot
512GB M.2 NVMe SSD (optional), 1TB M.2 NVMe SSD (optional)
2TB M.2 NVMe SSD (optional)
RF Options
RADIO
WLAN support
Bluetooth support
WWAN
4G LTE (optional), 5G (optional)
GNSS
GPS, GLONASS
RFID
HF RFID reader 13.56 MHz (optional)
Interfaces
PORTS
1 x USB 3.0 (Type-A), 1 x USB 3.0 (Type-C support power
delivery 20V In and ALT mode)
1 x Micro SDXC slot
1 x Nano SIM card slot
AUDIO
1 x Audio combo 3.5mm audio combo jack
Dual digital mic with noise cancellation
Dual speaker
CAMERA
Front: 2MP camera
Rear: 8MP with autofocus and LED light
DATA CAPTURE
1D/2D barcode reader (optional)
KEYS
1 x Power, 1 x Home
2 x Volume key
2 x Programmable function keys
LED INDICATORS
4x LED Indicator for power, Battery, HDD, RF status
CONNECTOR
1 x 19-pin docking connector
LAN
1 x RJ45-10/100/1000 GigaLAN port
Security
SOTI MobiControl
SOTI MobiControl compliance
KENSINGTON LOCK
Kensington lock support
Sensors
SENSORS
Light sensor
G-sensor
Gyro
Power Supply
BATTERY
Hot-swappable 11.55V, typ. 4558 mAh Li-Polymer battery (3S2P)
Optional 15.4V, typ. 5900 mAh Li-Polymer battery (4S1P)
OPERATING TIME
Standard battery: 8 hours
POWER RATING
19V DC
ADAPTER
100-240V, 50-60Hz / 19V DC
Operating Systems
WINDOWS
Windows 11 IoT Enterprise LTSC (64 bit)
Windows 10 IoT Enterprise LTSC (64 bit) (optional)
Physical Characteristics
DIMENSIONS
271.5 x 198.2 x 23.3 mm
WEIGHT
1.2 kg
COOLING SYSTEM
Fan design
Environment
OPERATING HUMIDITY
10% to 90% RH, non-condensing
OPERATING TEMP.
-20°C to 60°C
STORAGE TEMP.
-30°C to 70°C (-22°F to 158°F)
SHOCK
MIL-STD-810H Method 516.8 Procedure I
VIBRATION
MIL-STD-810H Method 514.8 Procedure I
DUST AND WATER
IP65
DROP
MIL-STD-810H Method 516.8, 4 ft
EMC
MIL-STD-461G CE102, RE102, CS118 (default)
MIL-STD-461G CS101, CS114, CS115, CS116, RS103 (optional)
Key features
- 10.1” 1920 x 1200 IPS LED panel with direct optical bonding
- Intel® Elkhart Lake Celeron® N6211 processor
- Low power consumption with fanless design
- Integrated 4G/5G wireless WWAN (optional)
- IP65 water and dust proof with MIL-STD-810H rugged housing
- USB Type-C port supports power delivery 20V In
- Removable battery with hot-swap function for all day productivity
- Sunlight readable with antiglare solution
Base Unit
PROCESSOR
Intel Celeron N6211 @1.20 GHz (up to 3.00 GHz)
Intel Pentium N6415 @1.20 GHz (up to 3.00 GHz) (optional)
MEMORY
4GB LPDDR4
8GB LPDDR4 (optional)
DISPLAY
10.1″ (1920×1200) 800 NIT
Optical bonding for sunlight viewability
Projected capacitive multi touch
Anti-glare touch treatment
Storage
STORAGE
128GB SSD
Additional storage available with micro SDXC card slot
256GB SSD (optional)
512GB SSD (optional)
RF Options
RADIO
WLAN support
Bluetooth support
WWAN
4G (optional)
5G (optional)
GNSS
GPS, GLONASS, Galileo, BeiDou
RFID
HF RFID 13.56 MHz reader (optional)
Add-on UHF RFID reader (optional)
Add-on smart card reader (optional)
Interfaces
PORTS
1 x USB 3.0 (Type-A), 1 x USB 3.0 (Type-C support power delivery
20V In)
1 x Micro SD card slot (support SDXC)
1 x SIM card slot
AUDIO
1 x Audio combo 3.5mm audio combo jack (Mic in or Line out)
Dual digital mic with noise cancellation
Dual speaker
CAMERA
Front: 2MP camera
Rear: 8MP camera with auto-focus and LED light
DATA CAPTURE
1D/2D barcode reader (optional)
KEYS
1 x Power, 1 x Home, 2 x Volume,
2 x Programmable function keys
LED INDICATORS
4x LED indicator for power, Battery, HDD, RF status
CONNECTOR
1 x 19-pin docking connector
Security
SOTI MobiControl
SOTI MobiControl compliance
LOCK
Kensington lock support
Sensors
SENSORS
Light sensor
G-sensor
Gyro
Power Supply
BATTERY
Hot-swappable 7.7V, typ. 5900 mAh Li-Polymer battery (2S1P)
7.4V, typ. 10280 mAh Li-Polymer battery (2S2P, optional)
ADAPTER
100-240V, 50-60Hz / 19V DC
OPERATING TIME
Standard battery: 9 hours
High capacity battery: 16 hours
POWER RATING
19V DC
Operating Systems
WINDOWS
Windows 11 IoT Enterprise LTSC (64 bit)
Windows 10 IoT Enterprise LTSC (64 bit) (optional)
Physical Characteristics
DIMENSONS
271.9 x 197.3 x 19.5 mm
WEIGHT
1.2 kg (2.65 lbs) with standard battery,
1.4 kg (3.1 lbs) with optional high capacity battery
COOLING SYSTEM
Fanless design
Environment
OPERATING HUMIDITY
10% to 90% RH, non-condensing
OPERATING TREMP.
-20°C to 60°C
STORAGE TEMP.
-30°C to 70°C (-22°F to 158°F)
SHOCK
MIL-STD-810G Method 516.6 Procedure I
VIBRATION
MIL-STD-810G Method 514.6 Procedure I
DUST AND WATER
IP65
DROP
MIL-STD-810G Method 516.6, 4 ft
